24-Hour Long-Range Monitoring
Supports continuous long-range monitoring for outdoor surveillance applications.
Smooth Image Performance
Provides delicate and smooth image output.
Convenient Installation and Application
Designed for practical deployment and field use.
360° Omnidirectional Pan-Tilt Coverage
Supports omnidirectional PT operation for wide-area monitoring coverage.
Thermal Imaging System
Uses a fifth-generation UFPA VOx detector with 640×512 resolution, optional 384×288, spectral range 7.5–14 μm, NETD 50mK (@25℃ F1.0), and 25–105 mm 5× continuous zoom lens with autofocus.
Visible-Light Camera
Uses a 1/2.8″ starlight CMOS sensor with 2 MP 1920×1080 resolution, low illumination capability, H.265/H.264 multi-stream encoding, and 8–320 mm motorized zoom lens.
Laser Illuminator (Optional)
Optional 8W 810nm military-grade infrared laser, with 1°–20° illumination angle and DSS digital step illumination angle control technology.
Intelligent Alarm Functions
Supports line crossing / intrusion detection, target tracking, 255-level alarm threshold setting, shot-point / fire detection alarm, multi-scene patrol detection, automatic tracking, panoramic stitching, and radar linkage.
PT System
Supports 50 kg payload, 0–360° pan, -45° to +45° tilt, pan speed 0.01–30°/s, tilt speed 0.01–15°/s, 255 presets, ±0.1° accuracy, and multiple cruise/scan modes.
Rugged Outdoor Design
Integrated aluminum alloy housing with stainless steel structure, optical glass window, waterproof connectors, thermal balance design, and IP66 protection.
