MR-LAD146-M Dispositivo de dispersión acústica

Inicio > Productos > MR-LAD146-M Dispositivo de dispersión acústica
MR-LAD146-M Dispositivo de dispersión acústica
MR-LAD146-M Dispositivo de dispersión acústica
Sistemas disuasorios no letales

Specification for MR-LAD146-M Acoustic Dispersal Device

Descripción del producto:

The MR-LAD146-M Portable Directional Acoustic Dispersal Device is a long-range directional acoustic emission system, also known as an acoustic dispersal device. It is a non-lethal acoustic deterrent device designed to focus and transmit sound within a narrow directional beam. By using advanced directional acoustic technology, the system enables long-distance voice transmission, warning, broadcasting, guidance, alerting, deterrence, and dispersal functions. It helps overcome the limited effective range of traditional security equipment and supports remote communication, proactive warning, deterrence, and incident prevention. The device is compact, lightweight, and suitable for field deployment. It can be used for military security, border protection, perimeter protection, emergency response, law enforcement, port security, prison protection, airport bird dispersal, and other security-related applications.

Obtener presupuesto gratuito

Presentación del producto

The MR-LAD146-M Portable Directional Acoustic Dispersal Device is designed for long-distance directional sound transmission. It concentrates acoustic energy into a narrow beam, allowing sound information to be transmitted accurately toward a designated area.

The system supports remote voice calling, broadcasting, command guidance, warning, alerting, deterrence, dispersal, and security prevention. It is suitable for scenarios where clear directional communication and non-lethal deterrence are required.

With a compact structure, weight below 4 kg, and dedicated battery power supply, the device supports mobile use and outdoor field operations.

Escenarios de aplicación

  • Sistema de Alarma Inteligente de Doble Espectro CT235HD

    Bomberos

  • Sistema de Alarma Inteligente de Doble Espectro CT235HD

    Protección perimetral

  • Sistema de Alarma Inteligente de Doble Espectro CT235HD

    Seguridad militar

  • Sistema de Alarma Inteligente de Doble Espectro CT235HD

    Lucha antiterrorista y mantenimiento de la estabilidad

Características del Producto y Especificaciones Técnicas

Long-Distance Transmission
The maximum transmission distance exceeds 1000 meters, supporting remote directional acoustic communication and deterrence.

Effective Warning Capability
The maximum warning distance exceeds 200 meters, enabling clear remote warning and alerting functions.

Compact and Lightweight Design
The device adopts a compact structure with a total weight of less than 4 kg, making it suitable for portable and field deployment.

Adaptabilidad ambiental
The product has passed strict military standard tests and can operate under harsh conditions such as extreme temperature, humidity, rain, salt fog, shock, and vibration.

Highly Directional and Clear Sound Output
It emits highly directional sound with clear voice information, enabling accurate communication and reducing interference from surrounding environments.

Dedicated Battery Power Supply
Equipped with a dedicated battery power system, the device can continuously operate for 4 hours after charging, meeting field operation requirements.

Parámetros Técnicos

Parámetro Especificación Parámetro Especificación
Modelo MR-LAD146-M Nombre del Producto Portable Directional Acoustic Dispersal Device
Nivel máximo de presión sonora ≥146 dB equivalent at 1 m Frecuencia 400 Hz – 6 kHz
Alimentación 40 W Sound Beam Constraint Angle < ±20°
Distancia de transmisión >1000 m Peso ≤4 kg
Método de almacenamiento de audio On-board large-capacity memory chip Clasificación de Protección IP65
Temperatura de funcionamiento -40°C ~ 70°C Temperatura de Almacenamiento -55°C ~ 85°C
Humedad operativa Enhanced cyclic humidity Prueba de lluvia GJB150.8A-2009, Procedimiento I
Prueba de calor húmedo GJB150.9A-2009 Salt Fog Test GJB150.11A-2009
Prueba de vibración GJB150.16A-2009 Prueba de choque GJB150.18A-2009

Efectos de la aplicación
